The Omron ZX “smart” laser sensor, a simple and elegant sensing solution, provides reliable, fast and accurate detection.
One Sensor For Any Measurement Application that Is Accurate and Easy to Use
- ZX2 ideal for measuring height/length, level detection, warpage, double feed detection, and wafer thickness
- Linearity accuracy better than ± 0.2% for all models over entire range
- Resolution of 1.5µm for ZX2 -LD50 Models
- Measurement period for ZX2 as short as 30µs ideal for measurement of fast moving objects
- User friendly “SMART” button on ZX2 Amplifier great for measuring objects on production line that are consistent, vary, or have variable surfaces from one work-piece to the next
- Amplifier display unit with easily readable characters reduces the need to use sensor manual to decode read out
- Four built-in bank functions in amplifier reduces space and set up time versus smart sensors with external banking units
Specifications:
- Measurement range of 50mm ± 10mm for ZX2-LD50 and 100mm ± 35mm for ZX2-LD100 Models
- Classified Laser Standards include Class 2 EN60825-1 and FDA Class II
- Applications include molded part shape validation, robot arm positioning, and tray warpage
- ZX2 Line Beam Models ideal for stable measurement on rough surfaces
- ZX2 Spot Beam Models ideal for making precision measurements on object surfaces
- Laser diode End of Life Alert allows for scheduled maintenance and continuous production
- Robot cable between sensor head and amplifier enables reliable sensing on moving parts
- Compact sensor head is 47.5mm L x 22.6mm W x 35.5mm H ideal for mounting in small spaces
- IP67 Rating allows sensor head to be used in harsh wet conditions
- Calculating Unit allows calculations between two sensors to appear on amplifier unit
